 VGT vs VNT?
Author Message

Joined: June 30th, 2010, 6:22 pm
Posts: 16
Post VGT vs VNT?
Hi.
Which system has better - spool time, controlling boost, less back pressure, higher efficiency? Which is lighter, stronger and simple?


August 13th, 2010, 6:42 pm
Profile
User avatar

Joined: January 12th, 2009, 9:20 am
Posts: 153
Location: Bismarck, ND
Post Re: VGT vs VNT?
2 slightly different ways to accoplish the same thing(from my experience).

VNT being(in the case of the Garrett GT3782VA from the 6.0L Ford powerstroke) 9 vanes that pivot on a unison ring to change the angle of the exhaust hitting the turbine wheel and also altering the a/r.

VGT being(in the case of the Holset HE351VE from the 6.7L cummins) a large slide that restricts the exhaust by moving linearly in/out.

There is one moving part in the exhaust with the Holset and 11 in the Garrett( 9 vanes, 1 unison ring, 1 actuator). I had 0 problems with reliability with the Garrett, no experience yet with the Holset. The Holset will flow much more air though as the GT3782VA is only really good for around 400 CFM if I remember correctly. I think the Holset will do more like 600 CFM.

Are there 2 particular turbos you had in mind for a particular project?

_________________
BOOST=My favorite drug.


August 15th, 2010, 9:35 pm
Profile

Joined: June 30th, 2010, 6:22 pm
Posts: 16
Post Re: VGT vs VNT?
I think to do some project with one of them but i am thinking about which system is better.


August 23rd, 2010, 4:16 am
Profile
User avatar

Joined: January 12th, 2009, 6:36 pm
Posts: 445
Post Re: VGT vs VNT?
I don't know much about either, but I would have to guess that VGT is better, simply because it has fewer moving parts, thus would be more reliable.

_________________


August 28th, 2010, 1:07 am
Profile
Admin
User avatar

Joined: December 13th, 2008, 2:22 pm
Posts: 809
Post Re: VGT vs VNT?
I do like the simplicity of the VGT over VNT. I think VNT may control boost on a gasoline engine better. VGT I should shed heat better, and handle higher EGTs since all the vanes are cast together.

Beyond that I don't know, not enough stuff is out there now for any kind of real comparison. I would really like to experiment with a VNT turbo.

One thing about VNT stuff, there are a lot more sizes to choose from. In the VGT world the HE341V is the smallest I've seen. VNT goes all the way down to the VNT15 in the TDI jettas. If they can handle the heat, it opens up a lot of options for smaller engines.

_________________

Self Cooling Intercooler
Quote:
Is there such a thing? What I am thinking of is something like like air/water intercooler but instead of water passing thru it, the turbo sucks air thru it, then feeds the charge thru the side where it normally would on an air water intercooler. Thus cooling itself

FAIL


August 28th, 2010, 7:36 am
